HIGH QUALITY YG13 EXCAVATOR
PHP 763,860
New
Mailing
Caloocan City
Description
Bumped
2 weeks ago
The Main Performance Parameter: Mini-excavator weight : kg 1200 Bucket capacity: m³ 0.03 Working device form Backhoe Model: KOOP Delivery capacity:0.449 Rated output power / speed :7.6/3000 kw/r/min Maximum torque: 25/2500 n.m./r/min SPEED Maximum travel speed :1.2 km/h Slewing speed:9rpm Maximum climbing ability: 30° Maximum digging force:6.5kn Ground pressure:0.4kgf/cm² Caterpillar band: rubber material Tension type: Grease cylinder hydraulic pump / form / gear pump Working pressure:16mpa Flow: 18/22/24 L/min hydraulic tank capacity:18L Engine oil capacity:1.65L Fuel tank capacity: 5.5L Total Length (transport time):2200mm Total width (transportation / operation):750mm Total height (with / without ceiling):2285(2030)mm Bulldozer blade width: 937mm Bulldozer blade height: 210mm Caterpillar band center distance:746mm Standard caterpillar band board width: 180mm Platform clearance:405mm Standard bucket width (with / without side teeth):380/330mm Total length of caterpillar band:1200mm Maximum excavation height:2490mm Maximum unloading height:1745mm Maximum excavation depth:1725mm Maximum vertical arm excavation depth:1655mm Maximum excavation distance: 3030mm Minimum turning radius at front end:1490mm Maximum excavation ground distance: 2940 Maximum bulldozing height:170mm Maximum bulldozing height:240mm
