Sony Cassette Deck TC-4300SD

A rare unit, tested and working perfectly fine but been in storage for a while. Requires 100v. Features: - Year of manufacture: 1975-1977. - Sony's first erect type deck series and this makes it easy for head cleaning and head degaussing easy. - Dolby-B noise reduction. - F & F (ferrite & ferrite) heads. - Single capstan. - Transport belt drive. - DC servomotor with frequency generator as a tape drive mechanism part. Since the rotation of this motor is smooth and the speed is controlled by the servo, it is not affected by the power supply frequency, and therefore is not required to switch cycles between 50 Hz and 60 Hz. Even when the power supply voltage changes, it maintains a constant rotation. - Timer standby switch is provided for timer recording/playback with an optional timer. While the timer is in standby, the pinch roller separates from the capstan so that no burden is imposed on the mechanism. - A 3-stage switchable tape selector with independent bias and equalizer. - In order to prevent distortion of sound due to unexpected excessive input, switchable peak limiter circuit developed by Sony is provided. - Tape counter with 3 digit display. - A level meter with backlight. - Auto shut-off mechanism. - See-through light behind the cassette allows you to check the remaining amount of tape. Specifications: Tape speed:          4.8cm/s Track system:         4 track 2 channel stereo Recording time:         Round trip 120 minutes (when using C-120) Recording bias frequency:   105kHz Overall SN ratio:        54dB (peak level) Dolby on: 5dB improvement                 (1kHz), 10dB improvement (5kHz or more) Overall strain rate:       1.7% (Fe - Cr) Frequency characteristic:   30Hz to 16kHz / 50Hz to 15kHz ± 3dB (Fe - Cr)             30Hz to 16kHz / 50Hz to 15kHz ± 3dB (CrO 2)             30Hz to 14kHz (normal) Wow/flutter:         0.09% wrms Input terminal:         Microphone jack (standard jack × 2)               　 Minimum input level: 0.2mV   　            Low impedance              Line input jack for microphone (pin jack × 2) 　            Minimum input level: 0.06V    　         Input impedance: 100kΩ or more Output terminal:   Line output jack (pin jack × 2)   　             Specified output: 0.435V (at 100 kΩ load) 　             Load impedance: 10kΩ or more            Stereo headphone jack × 1 　             Load impedance: 8Ω Recording connector:   Input impedance: 10kΩ or less             Output impedance: 10kΩ or less Semiconductors:     Transistor: 22 pieces            IC: 2 pieces             Diode: 8 pieces Power-supply voltage:  AC 100V, 50Hz/60Hz Power consumption:   6W External dimensions:   Width 360 × height 145 × depth 285mm Weight:          5.4kg
